Introduction
vector
CRYSTONITE is a surface applied 2 component crystalline slurry treatment with impregnation properties used for a concrete structure to protect against water ingress. It consists of active chemicals, special cementitious binders, and fillers mixed with a liquid polymer, which makes it concretely impervious to the penetration of water. When applied to concrete, CRYSTONITE chemically reacts with water and un-hydrated cement particles to form insoluble needle-shaped crystals that fill capillary pores and micro-cracks concrete and block the pathways for water and waterborne contaminants. CRYSTONITE protects from moisture and water ingress throughout the treated structure's life as the active compound forms crystals on contact with water.
Recommended   Application
plaster wall
Tunnels
concrete
Canals
ceilings
Reservoirs
plaster wall
Bridges
concrete
Dams
ceilings
Elevator pits
plaster wall
Swimming pools
concrete
Basement retaining walls
ceilings
Concrete slabs (floor/roof/ balcony, etc.)
plaster wall
Concrete foundations
plaster wall
Construction joints
plaster wall
New and old concrete
plaster wall
Brick and block masonry
plaster wall
Parking structures
concrete
Water retaining structures
ceilings
Underground vaults
plaster wall
subway systems
plaster wall
Sewage and water treatment plants
Benefits   &   key   features
line
benefit
IMPERMEABLE
benefit
IMPREGNATION PROPERTIES
benefit
DURABLE
benefit
RESIST HYDROSTATIC PRESSURE
benefit
EASY APPLICATION
benefit
POSITIVE AND NEGATIVE SIDE APPLICATION
benefit
SELF-HEALING PROPERTIES
Technical   Specification
line
Appearance
Light grey powder (A) and milky white Emulsion (B)
Mix density
1.8 g/cm³
Pot life@ 30°c
30 minutes
Hydrostatic pressure resistance
10 bars
Typical depth of crystal penetration
2-10 mm
Sealing cracks
up to 0.5mm
Adhesion to concrete
1.8 Mpa
Flexural strength
6 Мра
Co-efficient of water vapour diffusion resistance (u)
60
Mixing ratio
3 powder :1 liquid
Drying time
12 Hours
Packaging
30 kg combo
(part A: 21 kg and part B: 9 Ltr)
Coverage
1.8 kg/m² per single coat and 3.6 kg/m² for double coat
(Depending on numbers of coats and area)
• Single basements and water bodies are 2 to 3 kg/m²
• Toilets and sunken portions are 1.8 to 2 kg/m².
• Multi-level basements is 2.5 to 3.6 kg/m².
Shelf Life
12 months
from date of packing for sealed pack, stored in cool & dry condition, away from direct sunlight.
